2 Layer Hard Gold PCB Printed Circuit Board Fr4 Material Black Solder Mask

Name: 2 Layer Hard Gold PCB Printed Circuit Board Fr4 Material Black Solder Mask
Brand: WITGAIN PCB
Price: 1 USD

2 Layer Hard Gold PCB Printed Circuit Board Fr4 Material Black Solder Mask Manufactures

Brand Name : WITGAIN PCB

Model Number : P02E2660A0

Certification : UL CERTIFICATE

Place of Origin : CHINA

MOQ : negotiable

Price : negotiable

Payment Terms : T/T

Supply Ability : 1kkpcs/month

Delivery Time : 20 work days

Packaging Details : 1960pcs/bag, 10bags/carton

Material : FR4 TG170

Layer Count : 2Layer

Thickness : 0.8MM

Min Hole : 0.4MM

Min Line : 8/8MIL

Gold Thickness : 120U'

Copper : 1/1OZ

Color : Black

Surface Treatment : Gold Plating+Immersioni Gold

Contact Now

2 LAYER HEAVY GOLD Printed Circuit Board , FR4 Material , Black Solder Mask , Gold Plating

PCB Specifications:

Layer Count: 2 Layer Heavy Gold PCB

Board Thickness: 0.8M

Material: FR4 High TG170

Copper Thickness: 1/1OZ

Min Hole: 0.4MM

Min Line: 8/8 Mil

Hole: L1-L2 Vin In Pad, Resin Plugged in Holes

Solder Mask: Black

Surface Treatment: Hard Gold Plating+ENIG

Gold Thickness: 120U'+2U'

Application: Air Plane

Our Products&Services:

2 Layer Hard Gold PCB Printed Circuit Board Fr4 Material Black Solder Mask

FAQ:

Question: Why do you make so heavy gold on pcb? What is the function?

Answer: Because our customer require us to do that heavy gold. The pad will be rubbed many times. The heavy gold has good rub resistance feature.

Exhibitions:

2 Layer Hard Gold PCB Printed Circuit Board Fr4 Material Black Solder Mask
